Producător:
ZYXEL
-
Dimensiuni (L, L, H), mm:250 x 104 x 27 mm
-
Tip comutator:Fixed Port
-
Porturi principale, tip:8 x Multi-Gigabit (100M/1G/2.5G) RJ-45 PoE++ (60 W)
-
Alimentare prin Ethernet (PoE):8x PoE++ (IEEE 802.3bt, 60W), Total PoE budget:130W
-
Porturi uplink:2 x 1G SFP/10G SFP+
-
Sloturi gratuite (10 GB).:No
-
Stivuibil:No
-
Fans_TEXT:Fanless
-
Dirijare:Static, Routing table: 8
-
Memorie (Flash, RAM):Flash/RAM: 32 MB/256 MB; Packet buffer (byte): 1.5 MB
-
Capacitate de rutare/comutare, Gbps:80 Gbps
-
Debit, Mpps:59.5 Mpps
-
adrese MAC:16 K
-
VLAN (număr, standarde):802.1Q Static VLANs/Dynamic VLANs: 1 K/4 K; Port-based VLAN; Voice VLAN; VLAN trunking; MAC-based VLAN; Vendor ID based VLAN; VLAN routing
-
Standarde de rețea L2:IEEE 802.3ab/bz/ae/az
-
Standarde de rețea L3:802.1p, ICMPv6, IGMP
-
Funcționalitate IPv6:IP interface (IPv4/IPv6): 8/8; IPv6 over Ethernet; IPv6 addressing architecture; Dual stack; ICMPv6; MTU; DHCPv6; DAD; DHCP client IPv6; NTP Server (IPv4/IPv6)
-
Opțiune de montare:Wall-mount
-
:Input voltage of AC: 100 - 240 V AC, 50/60 Hz; Max. power consumption: 230.81W
-
:Standalone management by Web interface; Cloud management by Nebula Control Center; Management through Web, SNMP; Firmware upgrade by FTP/Web; Configuration saving and retrieving; Multiple login supported; DHCP
-
:Layer 2 MAC filtering; Static MAC forwarding; SSH v2; SSL; Port isolation/security; MAC freeze; CPU protection; SHA2 HTTPS Certification; Login authentication by RADIUS; RADIUS accounting; Authorization on RADIUS; Multiple RADIUS servers; DHCP Snooping
-
:No. of hardware queues per port: 8; 802.1p queuing methods: SPQ, WRR, WFQ; Storm control: broadcast, multicast, unknown unicast (DLF); Port-based rate limiting (ingress/ egress); DiffServ (DSCP)
-
:99
-
:10
